漲套結構包膠輪
詳細介紹
產品規格
| 物料編碼 | 型號 | 輪徑 | 輪寬 | 軸徑范圍 | 載重 |
| ZT200/85/** | 200 x 85 | 200 | 85 | 30-60 | 1360 |
| ZT230/82/** | 230 x 82 | 230 | 82 | 40-65 | 1508.8 |
| ZT200/80/** | 200 x 80 | 200 | 80 | 40-70 | 1280 |
| ZT250/50/** | 250 x 50 | 250 | 50 | 25-45 | 1000 |
| ZT250/60/** | 250 x 60 | 250 | 60 | 30-50 | 1200 |
| ZT250/80/** | 250 x 80 | 250 | 80 | 30-60 | 1600 |
| ZT280/50/** | 280 x 50 | 280 | 50 | 30-45 | 1120 |
| ZT280/80/** | 280 x 80 | 280 | 80 | 30-60 | 1792 |
| ZT300/50/** | 300 x 50 | 300 | 50 | 30-45 | 1200 |
| ZT300/60/** | 300 x 60 | 300 | 60 | 30-60 | 1440 |
| ZT300/80/** | 300 x 80 | 300 | 80 | 30-60 | 1920 |
| ZT350/80/** | 350 x 80 | 350 | 80 | 30-60 | 2240 |
| ZT350/100/** | 350 x 100 | 350 | 100 | 30-60 | 2800 |
| ZT350/120/** | 350 x 120 | 350 | 120 | 30-60 | 3360 |
| ZT360/80/** | 360 x 80 | 360 | 80 | 40-65 | 2304 |
| ZT360/100/** | 360 x 100 | 360 | 100 | 40-65 | 2880 |
| ZT360/120/** | 360 x 120 | 360 | 120 | 40-65 | 3456 |
| ZT400/80/** | 400 x 80 | 400 | 80 | 40-70 | 2560 |
| ZT400/100/** | 400 x 100 | 400 | 100 | 40-80 | 3200 |
| ZT400/150/** | 400 x 150 | 400 | 150 | 40-80 | 4800 |
| ZT450/150/** | 450 x 150 | 450 | 150 | 40-80 | 5400 |
| ZT500/150/** | 500 x 150 | 500 | 150 | 70-100 | 6000 |
